PIC16F628A

Microchip PIC16F628A Microcontroller
Availability :    1
৳132.9
Quantity :


PIC16F628A Flash 2KB 4MHz Microcontroller
  • Program Memory Type: Flash
  • Program Memory (KB): 3.5
  • CPU Speed (MIPS): 5
  • RAM Bytes: 224
  • Data EEPROM (bytes): 128
  • Digital Communication Peripherals: 1-UART
  • Capture/Compare/PWM Peripherals: 1 Input Capture, 1 CCP
  • Timers: 2 x 8-bit, 1 x 16-bit
  • Comparators: 2
  • Temperature Range (C): -40 to 125
  • Operating Voltage Range (V): 2 to 5.5
  • Pin Count: 18
This powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 18-pin package and is upwards compatible with the PIC16F628, PIC16C62XA, PIC16C5X and PIC12CXXX devices. The PIC16F628A features 4MHz internal oscillator, 128 bytes of EEPROM data memory, a capture/compare/PWM, a USART, 2 Comparators and a programmable voltage reference that make it ideal for analog/integrated level applications in automotive, industrial, appliances and consumer applications.
