C945 Transistor

C945 NPN Transistor
Availability :    4
৳6
Quantity :

C945 Transistor Specification


FEATURES / TECHNICAL SPECIFICATIONS:

  • Package Type: TO-92
  • Transistor Type: NPN
  • Max Collector Current(IC): 150mA
  • Max Collector-Emitter Voltage (VCE): 50V
  • Max Collector-Base Voltage (VCB): 60V
  • Max Emitter-Base Voltage (VEBO): 5V
  • Max Collector Dissipation (Pc): 400 miliWatt
  • Max Transition Frequency (fT): 200 MHz
  • Minimum & Maximum DC Current Gain (hFE): 70 – 700
  • Max Storage & Operating temperature Should Be: -55 to +150 Centigrade



PNP COMPLEMENTARY:

PNP Complementary of C945 is P331

  • Collector-Emitter Volt (Vceo): 50V
  • Collector-Base Volt (Vcbo): 60V
  • Collector Current (Ic): 0.15A
  • hfe: 70-700 @ 1mA
  • Power Dissipation (Ptot): 400mW
  • Current-Gain-Bandwidth (ftotal): 150MHz
  • Type: NPN
