HC-SR501 PIR Motion Detector Module

Pyroelectric Infrared Motion Sensor Module (HC-SR501)
Availability :    7
৳99.8
Quantity :

HC-SR501 PIR Motion Detector Module Specification


  • Operating voltage range: DC 4.5-20V
  • Quiescent Current: less than 50uA
  • Trigger: L can not be repeated trigger/H can be repeated trigger (Default repeated trigger)
  • Delay time: 5-200S (adjustable) the range is (0.xx second to tens of second)
  • Block time: 1S (default)Can be made a range(0.xx to tens of seconds
  • Angle Sensor: less than 100°
  • Lens size sensor: Diameter: 23mm (Default)
  • Board Dimensions: 32mm*24mm
This is a Pyroelectric Infrared PIR Motion Sensor Module that can be applied to security products, prototype projects or toys. The automatic sensor: to enter the sensor output range is high, people leave the sensor range of the automatic delay off high, output low.

No Document Available.
