HC-SR04 Ultrasonic Sensor

Sonar Sensor
Availability :    13
৳94.9 ৳119.9
Quantity :

HC-SR04 Ultrasonic Sensor Specification

Voltage: DC5V
Current: less 2mA
TTL: higher 5V
Sensing angle: Less than 15 degree
Sensing distance: 2cm-450 cm
Accuracy: about 0.3 cm
PCB Dimension: 4.5*2.0 cm
Connection: VCC, trig(Control), echo(Receive), Out, GND
The HC-SR04 ultrasonic sensor uses sonar to determine a distance to an object like bats or dolphins do. It offers excellent range accuracy and stable readings in an easy-to-use package. Its operation is not affected by sunlight or black material like Sharp rangefinders are (although acoustically soft materials like cloth can be difficult to detect). Ultrasonic Ranging Module HC-SR04 provides 2cm-300cm non-contact distance sensing capabilities, Ranging accuracy up to 3mm; module comprises an ultrasonic transmitter, a receiver, and a control circuit. Basic operating principle: 1. IO port TRIG trigger ranging to at least 10us high-level signal 2. The module automatically sends eight 40khz square wave, automatically detects whether a signal return 3. A signal to return to a high output through the IO port ECHO high duration of the ultrasound wave from the transmitter to the time of the return. Test distance = (high level time * sound velocity (340M / S)) / 2; Reliable, high performance, high accuracy, blind area within 2cm.
