Adjustable Boost Module with Display

xl6009 adjustable boost module with display
Availability :    4
Quantity :

Adjustable Boost Module with Display Specification

XL6009 DC-DC Adjustable Boost Module 4-5-32V-To-5-55V Output Adjustable With Voltmeter Display Function.


  1. Boost adjustable: 4.5-32V To 5-55V lithium battery charging boost discharge integrated module, adjustable module.

  2. High safety: with over-voltage protection, stable and reliable.

  3. Easy to operate: The product connection has a clear function mark and is easy to operate.

  4. Professional materials: The products are all industrial grades, which can work for a long time and have a long service life.

  5. Easy to carry: This product has a portable size so it is very easy to carry.

    • Color: bule

    • Working voltage: 3-32 (V)

    • Input current: 4A, no load 18mA (5V input, 8V output, no load less than 18mA. The higher the voltage, the greater the no-load current.)

    • Conversion efficiency: <94>

    • Switching frequency: 400KHz

    • Output ripple: 50mV (the higher the voltage, the larger the current, the larger the ripple)

    • Load adjustment rate: ±0.5%

    • Voltage regulation rate: ±0.5%

    • Working temperature: -40 ° C -+85 ° C

This product uses high-quality chip boost and adjustable safety. It can be applied to the boosting field where the output voltage is higher than the input input voltage, such as battery, power transformer, DIY adjustable power supply, 24V car pen power supply, industrial equipment step-down, 9-turn 12V, 12V to 18V, 18V Turn 24V and so on.
